SL - SERIES
Indoor architectural LED fixture, concave shape with concealed illumination, anti-glare nano technology, pendant, surface mount and recessed installation
LED: Samsung LED chips, 3000-5000K, Dynamic white and RGBW available 83CRI (90 optional)
Optical: Direct & Direct/Indirect configuration, 121° Beam Angle, UGR<19, PF>0.95
Construction: High grade aluminum extrusion, Die-cast end caps, nano technology reflector, built-in driver, powder coat finish, seamless continuous linear runs available, damp location
| Model | Size | Wattage | Lumen Output |
|---|---|---|---|
| TechoLED-SL-1-36-25-X | 36 x 0.72 x 3.14" | 25W | 2000Lm |
| TechoLED-SL-1-36-30-X | 36 x 0.72 x 3.14" | 30W | 2400Lm |
| TechoLED-SL-1-48-34-X | 48 x 0.72 x 3.14" | 34W | 2720Lm |
| TechoLED-SL-1-48-40-X | 48 x 0.72 x 3.14" | 40W | 3200Lm |
| TechoLED-SL-1-59-40-X | 59 x 0.72 x 3.14" | 40W | 3200Lm |
| TechoLED-SL-2-36-25-X | 36 x 0.78 x 3.7" | 25W | 2000Lm |
| TechoLED-SL-2-36-30-X | 36 x 0.78 x 3.7" | 30W | 2400Lm |
| TechoLED-SL-2-48-34-X | 48 x 0.78 x 3.7" | 34W | 2720Lm |
| TechoLED-SL-2-48-40-X | 48 x 0.78 x 3.7" | 40W | 3200Lm |
| TechoLED-SL-2-59-40-X | 59 x 0.78 x 3.7" | 40W | 3200Lm |
