BX M SERIES
The TechoLED BX series features specification-grade linear LED fixtures made from high-grade aluminum extrusions. Available in standard sizes from 2 to 8 feet, as well as custom lengths, these fixtures can be pendant, surface, or wall-mounted. With virtually limitless options for creating patterns and shapes, the BX series provides a versatile, cost-effective, and modern lighting solution.
LED: Samsung LED chips, 2700-5000K, tunable white and RGB/RGBW available, 90CRI, 50,000 hour rated lifespan. Custom lumen packages available.
Optical: Direct and direct/indirect illumination, 110° beam angle, UGR<19
Construction: Damp location listed, high grade aluminum extrusion, die cast end caps, PMMA diffuser, powder coat finish. X, T, L lit corners, wall to ceiling transitions, for smooth seamless patterns.
| Model | Size | Output | Color Temp. | Wattage | Lumen Output |
|---|---|---|---|---|---|
| TECHOLED-BX-M-D-2-30-U | 2' | Medium | 3000K | 18W | 1440Lm |
| TECHOLED-BX-M-D-4-30-U | 4' | Medium | 3000K | 36W | 2880Lm |
| TECHOLED-BX-M-D-6-30-U | 6' | Medium | 3000K | 54W | 4320Lm |
| TECHOLED-BX-M-D-8-30-U | 8' | Medium | 3000K | 72W | 5760Lm |
