IP-2R Series
IP-2R SERIES
Download
IES files
TECHOLED-IP2-R.zipCut sheets
TechoLED-IP-2R-SERIES.pdfIP-2R Series is specification grade, slim 2” outdoor architectural linear fixture, with IP65 – fully exposed to elements – rating, ability to do continuous linear runs. Recessed installation. Wide ranging customization options, from custom lumen packages, sizes and finishes. Great lighting solution for all modern exteriors.
LED: Samsung LED chips, 2700-5000K, tunable white and RGB/W available, 90CRI
Optical: Direct illumination, 106° beam angle
Construction: High grade aluminum extrusion, die cast end caps, PMMA diffuser, integral driver, powder coat finish, waterproof IP65, IK-8 impact rating,
| Model # | Length | Output | Color Temp. | Wattage | Lumen Output |
|---|---|---|---|---|---|
| TECHOLED-IP2R-D-4-LO-30 | 4' | Low | 3000K | 15W | 1440Lm |
| TECHOLED-IP2R-D-4-ME-30 | 4' | Medium | 3000K | 23W | 2208Lm |
| TECHOLED-IP2R-D-4-HI-30 | 4' | High | 3000K | 31W | 2976Lm |
| TECHOLED-IP2R-D-6-LO-30 | 6' | Low | 3000K | 23W | 2208Lm |
| TECHOLED-IP2R-D-6-ME-30 | 6' | Medium | 3000K | 34W | 3264Lm |
| TECHOLED-IP2R-D-6-HI-30 | 6' | High | 3000K | 45W | 4320Lm |
| TECHOLED-IP2R-D-8-LO-30 | 8' | Low | 3000K | 31W | 2976Lm |
| TECHOLED-IP2R-D-8-ME-30 | 8' | Medium | 3000K | 46W | 4416Lm |
| TECHOLED-IP2R-D-8-HI-30 | 8' | High | 3000K | 61W | 5856Lm |
